SBC-ET6ULL
$136.00 - $139.00Features:
- Processor: NXP i.MX6ULL ARM Cortex-A7 MIMX8MM6DVTLZAA
- DDR: 512MB
- Storage:4GB EMMC
- Item Name: SBC-IMX6ULL-E4C
- Working Temputure: 0-70°
Github:
- https://github.com/EMTOP-TECH/SBC-IMX6ULL
SBC-IMX8MM
$145.00 - $149.00Feature：
- Quad-core ARM Cortex-A53,Plus Cortex-M4,Reserve Jtag;
- On-board 2GB DDR4,16GB EMMC,8MB SPI FLASH;
- On-board WiFi / Bluetooth;
- On-board Gigabit Ethernet PHY;
- Yocto Linux with source code;
- Comes with user manual, ready-made system;
Github:
https://github.com/EMTOP-TECH/SOM-IMX8MM
SBC-IMX8MM-LPD4
$119.00 - $149.00Github: https://github.com/EMTOP-TECH/SOM-IMX8MM-LPD4
Feature：
- Quad-core ARM Cortex-A53,Plus Cortex-M4,Reserve Jtag;
- On-board 2GB LPDDR4,16GB EMMC,8MB SPI FLASH;
- On-board WiFi / Bluetooth;
- On-board Gigabit Ethernet PHY;
- Comes with user manual, ready-made system;
OS :
Yocto Linux including source code uboot/kernel/Filesystem
- Yocto-L6.1.22 Standalone Source Code
- Yocto-L6.1.22 Yocto Build Patch
- Ubuntu 22
Default Part Number: SBC-IMX8MM-L216CW feature with LPDDR4 2GB, EMMC 16GB, WIFI
SBC-IMX8MP
$206.00 - $209.00Default Part Number: SBC-IMX8MP-L432CW
- SBC-IMX8MP-L432CW Feature with 4GB LPDDR4,32GB EMMC,WIFI,NPU
Github:
- https://github.com/EMTOP-TECH/SOM-IMX8MP
HW Features:
- Soc:
- NXP i.MX8M Plus 4xCortex-A53@1.6-1.8GHz, 1xCortex-M7@800Mhz
- 2.3 TOP/s
- Memory:Support 2GB~8GB LPDDR4
- Storage:Support 16GB~64GB EMMC
- I/O:
- Connectivity: WiFi/BT Combo(on SOM)/2x GbE LAN port/1x RS485/1x CAN/1x PCIe(M2 Key M)
- I/O Interfaces: 14x GPIOs/2x DIN/2x DO
- USB: 2x USB2.0 host/1x USB3.0 host/1x USB3.0 host (M2 Key B)
- Display: 1x HDMI2.0A(1920 x 1080p60)/1x MIPI DSI/1x LVDS (single channel)
- Media: 2x MIPI CSI/Audio IN/Out
Software Features:
- Yocto OS: Yocto Linux, Uboot/Kernel/Filesystem Source Code
-
- Yocto-L5.15.32_2.0.0
- Yocto-L6.1.22.2.0.0 with QT6
- Yocto-L6.12.3
- Debian12 OS:Debian12,Uboot/Kernel/Filesystem Source Code
SBC-PH8700
$119.00 - $139.00Features:
- CPU:TI AM3358
- DDR: 512MB DDR3
- Storage: 4GB EMMC
Github:https://github.com/EMTOP-TECH/SOM-PH8700
SBC-PH8800 For SOM-PH8800
$89.00Features:
- CPU:TI Sitara ARM Cortex-A9 AM4378 Processor
- 1GB DDR3 SDRAM
- 4GB eMMC Flash
- I/Os/Interfaces: I2C、SPI、CAN、UART、MMC、I2S、LCD、Camera、RGMII、GPIO、Power signal, etc.
- Working Temperature: -45Degree-85Degree
Github:
- https://github.com/EMTOP-TECH/SOM-PH8800
SBC6000X
$139.00 - $169.00Features:
- Atmel AT91SAM9261S, ARM9,200MHz
- SDRAM 64MB
- NandFlash 128MB
SBC60A5
Original price was: $219.00.$179.00Current price is: $179.00.Features:
- CPU:Atmel ATSAMA5D34 Cortex-A5 536Mhz
- DDR2:512MB
- eMMC 4GB，DataFlash 4MB，SD card High-speed SD interface supports hot plugging
SBC6845
$209.00 - $219.00Feature:
-
ATMEL at91sam9g45 (arm 926ej-stm, main frequency 400MHz) industrial chip, compatible with at91sam9m10processor
-
128MB DDR2 SDRAM, 256MB nandflash, 4MB DataFlash on board
-
External expansion precision RTC, support multiple sizes of LCD display, CPU support maximum resolution 1280 * 860
-
On board 5-way serial port (com2 as RS485), 1-way can bus interface, 1-way road network interface, and support a variety of communication modes
-
One SPI bus, one IIC bus, one PWM signal and one 10bit ADC are expanded
-
Support Linux 2.6.30/wince 6.0 operating system, and provide all on-board peripheral driver instructions and related test procedures
Provide PCB&Schamatic Design Files for verified Customer
SBC8118
$139.00 - $169.00Features:
- Processor:375MHz TI AM1808 ARM926EJ-S Microcontroller, also supports 456MHz operation
- 128MByte Mobile DDR2
- 128MByte NAND Flash (on the rear of the board)
- 8Mbit SPI Flash
- Working Temperature: -45degree-85degree
- Provide PCB&Schematic Design Files for verified Customer
Github:
- https://github.com/EMTOP-TECH/MINI8118
SBC8140 Single Board Computer
Original price was: $249.00.$219.00Current price is: $219.00.Features：
- TI DM3730CUSA
- 512MByte DDR SDRAM, 166MHz
- 512MByte NAND Flash, 16bit
Github:
- https://github.com/EMTOP-TECH/MINI8510
SBC8600B
$129.00 - $149.00Features:
- CPU:TI AM3358 ARM Cortex-A8 microprocessor
- DDR3L:512MB
- Storage:512MB
- OS: Linux3.2, Linux4.1
Github: https://github.com/EMTOP-TECH/MINI8600B
